AP-300 is a modern and innovative Automated Perimeter that meets global standards for excellence around visual sensitivity testing, diagnosis and management of eye disease. AP-300 platform of advanced diagnostics uses Kinetic and Static Perimetry, including white/white perimetry, blue/yellow (SWAP – Short wavelength automated perimetry) and Flicker (critical flicker fusion perimetry) for early glaucoma detection plus real Goldmann Kinetic Perimetry. The device offers a wide range of strategies, fields and test parameters. Built-in camera provides automatic control of patient fixation. Built-in data analysis include regression analysis of the visual field on the basis of historical examinations and standardized ways of presenting and printing test results. Intuitive perimeter software allows easy operation and is designed to be operated using the touch screen. AP-300 design includes built-in high quality PC computer.
AP-300
HIGHLIGHTS
- Complete test and data analysis system
- Kinetic perimetry
- Blue-on-Yellow static perimetry
- Static perimetry
- Test fields
- Targeted perimetry
- Pattern calibration
- Installation flexibility
- Test result presentation
- Test parameters
Technical Data
|
Measurement bowl type |
Hemispherical 300mm radius with difusive surface |
| Maximum temporal range (degrees) | 80° |
| Stimulus | White-on-white Green-on-white Red-on-white Blue-on-yellow |
| Stimulus duration | 0.1 – 9.9s |
| Stimulus size | I-V |
| Stimulus intensity | 0.03asb to 10000asb in 15 3dB or 45 1dB steps |
| Visual field testing distance | 30 cm |
| Background illumination | White 10asb (3.2cd/m2) for red and green stimulus tests White 31.5asb (10cd/m2) for white stimulus tests Yellow 100cd/m2 for Blue-on-Yellow tests Automatic background illumination control |
| Fixation control | Heijl-Krakau blind spot monitor Eye tracking (video camera) Eye previev (video camera) |
| Test models | Supra threshold age corrected: Screeing Threshold: Full Threshold, Fast Threshold, Smart Threshold Others: 2-Zone, 3-Zone, Quantify Defect, Constant, Binocular, Bi-Driving, Targeted Perimetry, Neurological |
| Test field library | With concentric test point positions: Macula, Central 22°, Central 30°, Full, Driving, Wide, Glaucoma, Peripheral With square-grid position: Macula, 10-2, 24-2, 30-2 User defined test fields Bi-Driving, Industial Medicine, monocular, binocular |
| Kinetic perimetry | up to 8 izopter individual stimulus parameters (color, size, movement speed) for each isopter |
| Correction glass diameter | 38mm |
| Chinrest | Electrically driven in horizontal and vertical axis |
| Computer | Build-in PC Touch screen support |
| Printer | External or network printer |
| Additional software features | Automatic pupil diameter measurement Fovea threshold testing User management module Touch screen operation DICOM export Network connectivity Programming interface for EMR systems Data import from HFA devices Auto backup |
| Dimensions | Height: 637mm Width: 566mm Depth: 420 mm |
| Weight | 23kg |
| Power requirements | Voltage 110-230VAC Power 95W |
